Viewmax Commercial Sliding Windows
The View-Max window offers unparallel levels of flexibility by allowing designers and architects the choice of 76mm (Derwent) or 101.6mm (McArthur) framing to cater for both the slimline applications and those of a more robust commercial design.
The View-Max window offers the flexibility of single and double glazing options. The View-Max integrates a number of design initiatives unique to Newage Glass and Aluminium such as the proprietary locking, roller and drainage systems.
Developed specifically for multi-storey residential and architecturally designed housing View-Max windows offer superior weather, thermal and acoustic performance.
The Viewmax Commercial Sliding Windows are designed with a high-performance frame, offering long-lasting quality and minimal maintenance. Their versatile design and high-quality glazing options ensure that they can withstand diverse environmental conditions, providing excellent insulation and weather resistance.
Key Features:
- Large Glass Area: Maximizes natural light and visibility.
- Developed specifically for multi-storey residential, schools and architecturally designed housing
- 4mm up to 10.38mm monolithic glass and up to 18mm double glazed units
- Minimal Maintenance: Easy to clean and maintain.
- Commercially designed to suit 76mm and 101.6mm
- Superior thermal and acoustic performance (refer to test reports) • Superior weather performance
- Minimal processing, cost effective and simple fabrication
Technical Specifications
| Frame Dimensions |
Option 1: 76 x 35mm
Option 2: 101.6 x 44.5mm |
| Maximum Product Performance |
SLS (Pa): 2000 ULS (Pa): 6000 Water (Pa): 600 |
| Maximum Recommended Sizes |
Height: 1600 mm Sash Width: 1200 mm Weight: 50kg |
| Acoustic Performance |
Glass Type: Rw (C; Ctr)db 6.38mm Laminate: 31 (-0,-2) 10.38mm/ 12/ 6.38mm IGU: 34 (-1,-3) (10.38mm lam) |
| Thermal Performance |
Uw range SG: 4.7 – 6.6 SHGC range SG: 0.28 – 0.69 Uw range DG: 3.2 – 4.4 SHGC range DG: 0.16 – 0.6 |
| Glazing Details |
Single Glazed: 4 – 10.38mm Double Glazed: 18mm |
| Compatible Systems |
Derwent 76mm Centre Pocket Framing
McArthur Evo Centre Pocket Framing ecoFRAMEplus Centre Pocket Double Glazed Framing |
