Altitude Sliding Windows
Newage Glass and Aluminium presents the Altitude Sliding Window, an elegant and practical solution for residential and commercial spaces. Designed with sleek, contemporary lines and a space-saving sliding mechanism, the Altitude Sliding Window provides a large glass area, maximizing natural light and outdoor views. Its durable frame and advanced locking systems make it a secure and reliable choice for modern architecture.
Designed with top of the range sliding adjustable wheels which create minimal friction along an aluminium track.
Locking system is designed to be slimline within the stile.
The Altitude Sliding Window has an option to use stacking configurations to help create even wider openings with single or double glazed options available.
Can accommodate multiple of performance features such as security screen, flyscreen and low lights.
This Sliding window is modern, stylish and is available in multiple different colours.
Key Features:
- Single and double glazed options.
- Concealed drainage slots, high weather performance.
- Fully integrated security screen or flyscreen options available.
- Flush handle and lock with stile.
- Customizable Sizes: Available in various sizes and finishes to fit different designs.
- Proprietary hardware, specially designed to accompany this product.
- Accepts from 4mm to 12.4mm single glazed and up to 18mm double glazing units, allowing the designer to achieve the most demanding thermal and acoustic specifications.
- Noise Reduction: Helps reduce external noise with double glazing.
Technical Specifications
| Frame Dimensions |
Option 1: 76 x 46mm Option 2: 101.6 x 46mm Option 3: 150 x 46mm |
| Maximum Recommended Sizes |
Height:1800 mm Sash Width: 1500 mm Weight: 160kg |
| Acoustic Performance |
Glass Type: Rw (C; Ctr) 6.38mm Laminate: 32 (-2, -2) dB 10.38mm/12/6.38mm IGU: 36 (-0,-2) |
| Thermal Performance |
Uw range SG: 4.8 – 4.9 SHGC range SG: 0.36 – 0.40 Uw range DG: 3.6 – 4.2 SHGC range DG: 0.23 – 0.57 |
| Glazing Details |
Single Glazed: 4 – 12.4mm Double Glazed: 12.4 – 18.5mm |
| Compatible Systems | McArthur Evo Centre Pocket Framing |
